You’ve just heard the dreaded hum... then nothing. Your Defy top loader is full of dirty water, and the cycle won’t advance. Before you call a technician, let’s diagnose the issue systematically.
In this guide, we’ll check for blockages, test common culprits, and finally isolate a faulty drain pump.
⚠️ Safety First
- Unplug the machine before any physical inspection.
- Have a bucket, old towels, and a flat-head screwdriver ready.
- Water may spill – work in a well-ventilated area.
Step 1: Understand the Symptoms
Your Defy top loader likely:
- Stops mid-cycle with water still in the drum.
- Makes a humming or buzzing sound (pump trying to run).
- Displays an error code (e.g., E20 or E21 on digital models).
- Does not spin – the machine won’t spin with water inside.
✅ If there’s no sound at all when draining should start, suspect the pump or control board. If there’s a hum but no water movement, suspect a blockage or failed pump impeller.
Step 2: Check for a Blockage (Most Common Cause)
Blockages are cheap to fix and account for ~70% of drain issues. Let’s rule this out first.
2.1 Access the drain filter / pump area
- On most Defy top loaders, the drain pump is behind the lower front panel (kick plate). Remove 2–3 screws.
- Place towels and a shallow bucket underneath.
2.2 Open the drain hose (emergency drain)
- Pull out the small drain hose (if present) and let water flow into the bucket.
- If no emergency hose, carefully unscrew the filter cap (turn anti-clockwise).
2.3 Inspect for debris
- You’ll likely find coins, hairpins, lint, or sock fibres.
- Clean the filter housing thoroughly.
- Check the pump impeller (visible through the opening) – spin it with a screwdriver. It should turn freely.
2.4 Check the main drain hose
- Disconnect the hose from the back of the machine.
- Blow through it or run water from a tap into it. If water flows out the other end, it’s clear.
- Check the standpipe on your wall – if it’s blocked, water backs up.
Result after cleaning?
- ✅ Water drains → problem solved (no cost, just your time).
- ❌ Still no drain → move to Step 3.
Step 3: Listen to the Pump
Put the machine into a drain-only or spin cycle. Listen carefully near the pump:
No data to display.
If you hear nothing (no hum, no vibration), use a multimeter to check for voltage at the pump terminals (next step).
Step 4: Test the Drain Pump Electrically
A replacement drain pump for a Defy top loader costs roughly R350 – R750 depending on the model (e.g., Defy DTL, DTD series). Before buying one, confirm it’s faulty.
Tools needed:
- Multimeter (set to ohms / continuity)
- Screwdriver
Procedure:
- Unplug the machine.
- Disconnect the two wires from the pump motor.
- Measure resistance across the pump terminals:
- Normal: 10–50 ohms (typically 15–30Ω)
- Open circuit (∞): Motor winding burnt → replace pump
- Short circuit (0Ω): Also faulty
- If resistance is normal, the pump might still be seized. Test by manually turning the impeller (should spin freely).
Also check for power:
- Reconnect wires, set machine to drain cycle, and measure AC voltage at the pump connector (carefully).
- Should read 220–240V for a few minutes during drain.
- No voltage → control board or wiring issue (less common).
In our case, the multimeter showed no continuity (open circuit). The pump motor was dead.
Step 5: Confirm It’s Not the Pressure Switch or Blocked Hose
A blocked pressure switch tube can trick the machine into thinking water is still present.
- Locate the pressure switch (usually near the top control panel).
- Blow gently into its hose – you should hear a click.
- If clear, move on.
Our pressure switch clicked normally, so it wasn’t the culprit.
Step 6: Replace the Faulty Drain Pump
Parts cost: R590 for a compatible Defy drain pump (tested on a DTL140 model).
DIY labour: Free. Technician call-out fee: ~R550–R800 extra.
Replacement steps (quick version):
- Unplug + drain remaining water via the filter.
- Remove pump mounting screws (2x).
- Twist off pump from its hose clamps (pliers may help).
- Swap wire terminals to the new pump (same positions).
- Reassemble and run a rinse cycle to test.
After replacement, the machine drained perfectly – no error codes, no humming.
Final Cost Summary (ZAR)
No data to display.
Total DIY cost: ~R590
Total with technician: ~R1,150 – R1,400
When to Call a Pro
- You’re uncomfortable working with electricity or water.
- Replacing the pump doesn’t solve the issue (could be main control board – R1,200+).
- The machine still won’t drain after a new pump – check wiring harness or timer.
Prevent Future Pump Failures
- Use a filter sock on the drain hose inside the drum (for lint).
- Run a monthly empty hot wash with 2 cups of white vinegar.
- Don’t overload – this strains the pump motor.
Conclusion
A top loader that won’t drain is frustrating, but the fix is often simple. Start with the cheap stuff (blockages), then move to electrical testing. In this case, the pump showed open circuit – a classic sign of thermal burnout.
A new pump at R590 restored full function. Your Defy should be back to spinning and draining in under an hour.
